山東制氮機常見的故障處理方式

制氮機設備在運行時難免會出現故障，制氮機噴篩及碳分子篩粉化就是制氮機在使用過程中一個比較常見的故障，今天山東制氮機制廠家的小編為您介紹下：

It is inevitable that the nitrogen generator equipment will break down when it is running. The spray screen and carbon molecular sieve pulverization of the nitrogen generator are common faults in the use of the nitrogen generator. The editor of Shandong nitrogen making mechanism manufacturer will introduce the following for you:

制氮機的控制系統：

Control system of nitrogen generator:

1、電氣控制系統：由PLC、電路系統、儀表、閥門組成。

1. Electrical control system: composed of PLC, circuit system, instrument and valve.

2、空氣緩沖罐：由空氣儲罐、閥門等組成，主要用于保證用氣的平穩。

2. Air buffer tank: composed of air storage tank, valve, etc., it is mainly used to ensure the stable use of gas.

3、氮?dú)饩彌_罐：由氮?dú)鈨?chǔ)罐、閥門組成，儲存氮?dú)?，主要是保證用氣的平穩。

3. Nitrogen buffer tank: it is composed of nitrogen storage tank and valve to store nitrogen, mainly to ensure the stable use of gas.

4、制氮機主機：由兩個裝滿碳分子篩的吸附塔和自動控制閥門組成，可以說是制氮機的核心。

4. Main engine of nitrogen generator: it is composed of two adsorption towers filled with carbon molecular sieve and automatic control valve, which can be said to be the core of nitrogen generator.

5、空氣凈化系統：由冷干機、過濾器、除油過濾器等組成，主要用于凈化空氣，除塵除水除油。

5. Air purification system: it is composed of cold dryer, filter and oil removal filter. It is mainly used to purify air, remove dust, water and oil.

隨著制氮機的分子篩壓力磨擦和使用時間的增加，制氮機分子篩壽命也隨之減少，時間一長分子篩就容易產生粉化的現象。特別容易發生在以氣缸壓緊的制氮機上、彈簧壓緊的制氮機上也容易發生此類故障，雖說椰墊法蘭壓緊不可監控，但是制氮機出廠之前，生產廠家在碳分子篩裝填過程中會十分小心，并有專用的壓緊工具和壓緊方法，反而產生制氮機碳分子篩粉化，噴篩的故障反而更低！

With the increase of pressure friction and service time of molecular sieve in nitrogen generator, the service life of molecular sieve of nitrogen generator is also reduced, and the phenomenon of pulverization is easy to occur over a long time. It is especially easy to occur on the nitrogen generator compressed by cylinder and spring. Although the coconut gasket flange pressing can not be monitored, the manufacturer will be very careful in the loading process of carbon molecular sieve before the nitrogen generator leaves the factory, and there are special pressing tools and pressing methods. On the contrary, the carbon molecular sieve of the nitrogen generator will be powdered, and the fault of sieve spraying will be on the contrary Lower!

制氮機噴篩、制氮機碳分子篩粉化直接的現象就是制氮機現場一片烏黑，再次因?yàn)樘挤肿雍Y價格昂貴，粉化的碳分子篩不可以再次被使用，重新購買新分子篩又是一筆費用，碳分子篩粉化還會造成制氮機管道閥門磨損嚴重，造成制氮機系統串氣，吸附壓力上不來氮?dú)庵笜?biāo)嚴重不足。

The phenomenon of direct pulverization of carbon molecular sieve in nitrogen generator and spray sieve in nitrogen generator is that the site of nitrogen generator is black. Again, because carbon molecular sieve is expensive, powdered carbon molecular sieve can not be used again. It is also a cost to purchase new molecular sieve. Pulverization of carbon molecular sieve will cause serious wear of pipeline valve of nitrogen generator, resulting in air entrainment in nitrogen generator system and no nitrogen on adsorption pressure The gas index is seriously insufficient.

以上就是小編為您介紹的山東制氮機噴篩故障的原因，希望為大家?guī)?lái)幫助！如需了解更多的精彩內容請關注公司網站：http://556rte.cn

The above is the reason for the failure of spray screen of Shandong nitrogen machine introduced by Xiaobian. I hope to help you! For more information, please visit our website: http://556rte.cn
